Application Scenarios
KCJN-809 is engineered for easy filling, sealing, waterproofing, and providing corrosion protection in electrical joints, various pipes, and irregularly shaped connections.
Product Performance Table
| Available Model | KCJN-809 |
|---|---|
Dimensions (T x W x L) | 3.0 mm x 96 mm x 3,000 mm (0.118" x 3.780" x 9.843') |
| Base Material | IIR |
| Dielectric Breakdown Strength | 16.1 kV/mm |
| Volume Resistivity | 2.9×1013 Ω·cm |
| Elongation at Break | 1,000% |
Drip Point Temperature (130°C/266°F × 24 h) | No dripping |
Low Temperature Resistance (-40°C/-40°F x 168 h) | No cracking |
| Peel Strength | 69.3 N/50 mm |
(Typical Values)
*Dimensions are customizable upon request.
Installation Guide
To apply Waterproof Mastic KCJN-809, remove the liner and wrap KCJN-809 around the target area, or embed the mastic directly into areas that require filling, insulation, sealing, and waterproof protection.
