Application Scenarios
Designed to protect all cable types against abrasion, water ingress, and fire hazards.
Product Performance Table
| Available Model | KCJ-85 |
|---|---|
Dimensions (T x W x L) | 1.65 mm x 50 mm x 3,000 mm (0.065" x 1.969" x 9.843') |
| Base Material | IIR + EPR |
| Tensile Strength | 8.5 MPa |
| Elongation at Break | 550% |
| Continuous Operating Temperature | 90°C/194°F |
| Dielectric Strength | 18.1 kV/mm |
| Flammability Rating | V0 |
(Typical Values)
*Dimensions are customizable upon request.
Installation Guide
Remove the release liner and stretch the Waterproof Insulating Tape KCJ-85 by approximately 200%. Apply the tape over the target area in successive half-lapped, level-wound layers until the desired thickness is achieved.
