Application Scenarios
Designed for a variety of electrical and insulation tasks in industrial and commercial environments, these products are ideal for general insulation, splicing, sealing protection, phase identification, jacket repair and wire harnessing up to 1 kV.
Selection Chart
 |  |  | |
|---|---|---|---|
| Available Models | KCVJ | KCVT | KCVM |
| Thickness | 0.13 mm (0.005") | 0.18 mm (0.007") | 0.65 mm (0.026") |
| Width | 19 mm (0.748") | 50 mm (1.969") | 38 mm (1.496") |
| Length | 5,000 mm (16.404') | 10,000 mm (32.808') | 6,000 mm (19.685') |
Installation Temperature | -10°C ~ 40°C (14°F ~ 104°F) | -10°C ~ 40°C (14°F ~ 104°F) | -10°C ~ 40°C (14°F ~ 104°F) |
| Base Material | PVC | PVC | PVC + IIR |
*Dimensions are customizable upon request.
Product Performance Table
| Available Models | KCVJ | KCVT | KCVM |
|---|---|---|---|
| Tensile Strength | 11.53 MPa | 17.90 MPa | 2.50 MPa |
| Elongation at Break | 230% | 250% | 150% |
| Dielectric Strength | 45.0 kV/mm | 37.0 kV/mm | 19.5 kV/mm |
| Volume Resistivity | 3.0×1014 Ω·cm | 4.0×1014 Ω·cm | 4.3×1014 Ω·cm |
| Continuous Operating Temperature | 80°C/176°F | 80°C/176°F | 80°C/176°F |
| Peel Strength | 4.5 N/25 mm | 4.0 N/25 mm | 5.0 N/25 mm |
(Typical Values)
Installation Guide
Apply PVC Vinyl Electrical Tape over the target area in successive half-lapped, level-wound layers. Maintain sufficient tension to ensure uniform wrapping. The start and end points of the tape should extend 10-20 mm beyond the covered area.
